Facts:
●High performance motor with innovative electronics, and energy saving up to 65%
●IC electronic detection, automatic power-off protection upon no water
●Motor Protection if rotor is blocked
●High pump heads and larger flow
●Can pump dirt particles of size up to 6mm
●Adopt wear proof ceramic shaft which can be used in a longer time
Application:1.Fountain displays 2.Waterfalls 3.Brooks 4.Gargoyles 5.Natural stone fountains 6.Filter operations 7.water circulations 8.Non-submersible installation
|
Model
|
Voltage |
Watts |
Q max.(l/h) |
H max.(m) |
Package LxWxH(mm) |
|
CM-13000 |
220-240V 50Hz |
110 |
13000 |
5.5 |
325x175x195 |
|
CM -15000 |
220-240V 50Hz |
135 |
15000 |
6.0 |
325x175x195 |
|
CM -18000 |
220-240V 50Hz |
170 |
17500 |
6.5 |
325x175x195 |
|
CM -20000 |
220-240V 50Hz |
200 |
19000 |
7.0 |
325x175x195 |
|
CM -12000LV |
AC12V |
90 |
12000 |
5.5 |
325x175x195 |
|
CM -15000LV |
AC12V |
135 |
15000 |
6.0 |
325x175x195 |
