Facts:
●High performance motor with innovative electronics, and energy saving up to 65%
●IC electronic detection, automatic power-off protection upon no water
●Motor Protection if rotor is blocked
●High pump heads and larger flow
●Can pump dirt particles of size up to 6mm
●Adopt wear proof ceramic shaft which can be used in a longer time
Application:1.Fountain displays 2.Waterfalls 3.Brooks 4.Gargoyles 5.Natural stone fountains 6.Filter operations 7.water circulations 8.Non-submersible installation
|
Model
|
Voltage |
Watts |
Q max.(l/h) |
H max.(m) |
Dim.LxWxH(mm) |
Package LxWxH(mm) |
|
|
DM-3000 |
220-240V 50Hz |
25 |
3000 |
3.0 |
188x104x128 |
260x175x185 |
|
|
DM -5000 |
220-240V 50Hz |
40 |
5000 |
3.5 |
188x104x128 |
260x175x185 |
|
|
DM -6500 |
220-240V 50Hz |
50 |
6500 |
4.0 |
188x104x128 |
260x175x185 |
|
|
DM -8000 |
220-240V 50Hz |
70 |
8000 |
4.5 |
188x104x128 |
260x175x185 |
|
|
DM -10000 |
220-240V 50Hz |
85 |
10000 |
5.0 |
188x104x128 |
260x175x185 |
|
|
DM -3000LV |
AC12V |
30 |
3000 |
3.0 |
188x104x128 |
260x175x185 |
|
|
DM -5000LV |
AC12V |
40 |
5000 |
3.5 |
188x104x128 |
260x175x185 |
|
|
DM -6500LV |
AC12V |
50 |
6500 |
4.0 |
188x104x128 |
260x175x185 |
|
|
DM -8000LV |
AC12V |
70 |
8000 |
4.5 |
188x104x128 |
260x175x185 |
|
|
DM -10000LV |
AC12V |
85 |
10000 |
5.0 |
188x104x128 |
260x175x185 |
|
