Facts:
●High performance motor with innovative electronics, and energy saving up to 65%
●IC electronic detection, automatic power-off protection upon no water
●Motor Protection if rotor is blocked
●High pump heads and larger flow
●Can pump dirt particles of size up to 6mm
●Adopt wear proof ceramic shaft which can be used in a longer time
Application:1.Fountain displays 2.Waterfalls 3.Brooks 4.Gargoyles 5.Natural stone fountains 6.Filter operations 7.Water circulations
|
Model |
Voltage |
Watts |
Q max.(l/h) |
H max.(m) |
Package LxWxH(mm) |
|
EMP-3000 |
220-240V 50Hz 120V 60Hz |
25 |
3500 |
3.0 |
430 x 300x180 |
|
EMP -5000 |
220-240V 50Hz 120V 60Hz |
40 |
5000 |
3.5 |
430 x 300x180 |
|
EMP -6500 |
220-240V 50Hz 120V 60Hz |
50 |
6500 |
4.0 |
430 x 300x180 |
|
EMP -8000 |
220-240V 50Hz 120V 60Hz |
70 |
8000 |
4.5 |
430 x 300x180 |
|
EMP -10000 |
220-240V 50Hz 120V 60Hz |
85 |
10000 |
5.0 |
430 x 300x180 |
|
EMP -13000 |
220-240V 50Hz 120V 60Hz |
110 |
13000 |
5.5 |
430 x 300x180 |
|
EMP -15000 |
220-240V 50Hz 120V 60Hz |
135 |
15000 |
6.0 |
430 x 300x180 |
|
EMP -18000 |
220-240V 50Hz 120V 60Hz |
170 |
17500 |
6.5 |
430 x 300x180 |
|
EMP -20000 |
220-240V 50Hz 120V 60Hz |
200 |
19000 |
7.0 |
430 x 300x180 |
|
EMP -3000LV |
AC12V |
30 |
3500 |
3.0 |
430 x 300x180 |
|
EMP -5000LV |
AC12V |
40 |
5000 |
3.5 |
430 x 300x180 |
|
EMP -6500LV |
AC12V |
50 |
6500 |
4.0 |
430 x 300x180 |
|
EMP -8000LV |
AC12V |
70 |
8000 |
4.5 |
430 x 300x180 |
|
EMP -10000LV |
AC12V |
85 |
10000 |
5.0 |
430 x 300x180 |
|
EMP -12000LV |
AC12V |
90 |
12000 |
5.5 |
430 x 300x180 |
|
EMP -15000LV |
AC12V |
135 |
15000 |
6.0 |
430 x 300x180 |
