Facts:
●High performance motor with innovative electronics, and energy saving up to 65%
●IC electronic detection, automatic power-off protection upon no water
●Motor Protection if rotor is blocked
●High pump heads and larger flow
●Can pump dirt particles of size up to 6mm
●Adopt wear proof ceramic shaft which can be used in a longer time
Application:1.Fountain displays 2.Waterfalls 3.Brooks 4.Gargoyles 5.Natural stone fountains 6.Filter operations 7.Water circulations
|
Model |
Voltage |
Watts |
Q max.(l/h) |
H max.(m) |
Outlet |
Package LxWxH(mm) |
|
TMP-3500 |
220-240V 50Hz 120V 60Hz |
30 |
3500 |
3.0 |
¾”1”1¼”1½” |
300 x300 x140 |
|
TMP-5000 |
220-240V 50Hz 120V 60Hz |
40 |
5000 |
3.5 |
¾”1”1¼”1½” |
300 x300 x140 |
|
TMP-6500 |
220-240V 50Hz 120V 60Hz |
50 |
6500 |
4.0 |
¾”1”1¼”1½” |
300 x300 x140 |
|
TMP-8000 |
220-240V 50Hz 120V 60Hz |
65 |
8000 |
4.5 |
¾”1”1¼”1½” |
300 x300 x140 |
|
TMP-10000 |
220-240V 50Hz 120V 60Hz |
75 |
10000 |
5.0 |
¾”1”1¼”1½” |
300 x300 x140 |
|
TMP-3500 LV |
AC 12V |
30 |
3500 |
3.0 |
¾”1”1¼”1½” |
300 x300 x140 |
|
TMP-5000V |
AC 12V |
40 |
5000 |
3.5 |
¾”1”1¼”1½” |
300 x300 x140 |
|
TMP-6500 LV |
AC 12V |
50 |
6500 |
4.0 |
¾”1”1¼”1½” |
300 x300 x140 |
|
TMP-8000 LV |
AC 12V |
65 |
8000 |
4.5 |
¾”1”1¼”1½” |
300 x300 x140 |
|
TMP-10000LV |
AC 12V |
75 |
10000 |
5.0 |
¾”1”1¼”1½” |
300 x300 x140 |
